Product Overview



Hydraulic plugs are precision permanent sealing components engineered to close cross-drilled fluid passages in hydraulic manifolds, valve blocks, transmission housings, and high-pressure fluid power systems. By utilizing a controlled two-piece expansion mechanism (sleeve and internal core pin), these plugs generate high radial expansion forces against the bore wall, achieving a reliable metal-to-metal seal without threading or O-rings. Designed in compliance with ISO and DIN standards to withstand extreme operating pressures and high-frequency pressure spikes, they prevent internal fluid bypassing and external leakage in demanding off-highway, industrial, and mobile hydraulic applications.


  • Hydraulic Cap
    Used to seal pipe ports and prevent fluid leakage. Easy to install, it can temporarily or permanently seal pipelines, ensuring a reliable system seal.
  • Hydraulic Blind Plug
    Used to seal pipe ports and prevent fluid leakage. Easy to install, it can temporarily or permanently seal pipelines, ensuring a reliable system seal.
  • Hydraulic Blanking Plug Kit
    Used to seal pipe ports and prevent fluid leakage. Easy to install, it can temporarily or permanently seal pipelines, ensuring a reliable system seal.
  • Hydraulic Plug With O Ring
    Used to seal pipe ports and prevent fluid leakage. Easy to install, it can temporarily or permanently seal pipelines, ensuring a reliable system seal.


Product Types





Standard Expansion Plug (KOENIG / SFC Style)

Two-piece design featuring an outer sleeve and internal expansion pin. Axial insertion of the pin expands the sleeve outward to bite into the parent material bore. Suitable for aluminum, cast iron, and steel manifolds.



Sealed-End Expansion Plug

Features a closed-bottom design to completely block fluid passage, eliminating any path for fluid migration through the center of the plug under high pressure.



Threaded Hex Plug (Low/Medium Pressure)

Used in auxiliary ports or non-critical lines where removable servicing is required, typically sealed with a copper/metal washer or parallel thread O-ring.





Key Features

High Pressure Resistance

Withstands working pressures up to 50 MPa (7,250 psi) and burst pressures exceeding 80 MPa (11,600 psi), verified per ASTM standards.



Vibration & Impulse Stability

Resists loosening under high-frequency pressure cycles and heavy mechanical vibration typical in excavator and loader hydraulic circuits.

Threadless Installation

Eliminates the machining time and cost of tapping internal threads in cross-drilled holes.

Parent Material-Optimized Spring-Back Management

Engineered with specific sleeve hardness differentials to account for the varying elastic recovery (spring-back coefficients) of light alloys (e.g., 6061-T6 aluminum vs. ductile iron), preventing housing cracking while maintaining permanent frictional engagement.

Leak-Proof Performance

Metal-to-metal interference fit maintains hermetic sealing across wide temperature fluctuations (-40°C to +150°C).



Technical Specifications



Parameter

Specification Details

Available Diameter Range

3.0 mm to 22.0 mm (Custom fractional & inch sizes available upon request)

Hole Diameter Tolerance

ISO H7 or H11 (Dependent on plug series and parent material)

Bore Surface Finish

Ra <= 1.6 um (Recommended for optimal frictional bite)

Operating Pressure Range

Up to 50 MPa (7,250 psi)

Standard Materials

Stainless Steel (AISI 304 / 316), Carbon Steel (Zinc-plated), Aluminum Alloy, Brass

Surface Treatment

Zinc Plated (Clear/Yellow passivated, min. 8-12 um per ASTM B633), Electroless Nickel Plating (ASTM B733), Passivated (ASTM A967)

Operating Temperature

-40°C to +150°C (-40°F to +302°F)

Applicable Parent Materials

Cast Iron, Ductile Iron (EN-GJS-400/500), Aluminum Alloys (6061/7075), Carbon Steel, Forged Steel

Compliance & Quality Standards

ISO 9001:2015, IATF 16949, ISO 4406 (Cleanliness standards)



Manufacturing Process


Cold Heading & Precision Turning

Sleeves and pins are formed via multi-axis CNC Swiss lathes to maintain strict concentricity and outer diameter tolerances within +/- 0.01 mm.

Heat Treatment

Controlled atmosphere annealing or quenching (per ISO 683 / ASTM A276) to achieve the precise hardness differential between the expandable sleeve and the rigid core pin.

Surface Finishing

Automated barrel plating or rack plating lines apply uniform protective coatings to prevent galvanic corrosion when inserted into aluminum manifolds.

100% Dimensional Sorting

Optical sorting machines inspect every batch for outer diameter, length, and wall thickness consistency before packaging.





Applications

Hydraulic Manifold Blocks: Closing cross-drilled oil galleries and intersecting internal channels in custom or standard valve blocks.


Heavy Machinery & Off-Highway Equipment: Used in excavators, wheel loaders, cranes, and agricultural tractor hydraulic transmission systems.


Automotive Powertrain: Engine block oil passages, automatic transmission valve bodies, and steering gear housings.


Industrial Automation: Hydraulic power units (HPUs), injection molding machine hydraulic manifolds, and metal-cutting machine tool hydraulic systems.

Hydraulic Blind Plug



OEM & ODM Customization

We partner directly with fluid power OEMs and Tier-1 system integrators to engineer application-specific sealing solutions:

Custom Dimensions

Non-standard metric and imperial diameters, extended lengths, or specialized wall thicknesses for unique bore geometries.

Material Certification

Full material traceability with EN 10204 3.1 material test certificates for critical safety applications.

Special Coatings

Cadmium-free plating, high-temperature passivations, or specific torque-tension modifications.

Engineering Support

Finite Element Analysis (FEA) data support and pull-out force test reports provided for custom prototype validation.



Hydraulic Blind Plug factory



Quality Control

Raw Material Verification: Spectrometer material composition analysis prior to production.


Pull-Out Force Testing: Destructive and non-destructive axial pull-out resistance tests conducted per batch on calibrated load frames in accordance with internal test procedures modeled after ISO standards.


Pressure Burst Testing: Hydrostatic pressure testing up to destruction limits to verify safety margins.


PPAP Documentation: Level 1 through Level 3 PPAP documentation packages available upon customer request for automotive and aerospace supply chains.



Packaging & Shipping

Anti-Corrosion Packaging

VCI (Volatile Corrosion Inhibitor) bags combined with moisture-barrier vacuum sealing to prevent oxidation during ocean or air transit, conforming to MIL-PRF-81705 standards.

Bulk & Tray Packaging

Organized in compartmentalized anti-static grid trays or industrial bulk bags labeled with part number, batch number, heat code, and quantity for automated pick-and-place assembly lines.

Global Logistics

Ex Works, FOB, CIF, or DDP shipping terms supported via air freight (DHL/FedEx for samples) or sea freight (containerized pallet shipments).





FAQ





Q: What hole tolerance is required in the manifold block for proper installation?

A: Standard installation requires an ISO H7 or H11 bore tolerance, depending on the plug series. Proper surface finish of the drilled hole (Ra <= 1.6 um) is essential to ensure maximum frictional engagement and seal integrity.

Q: How do different parent materials affect the selection of expansion plugs?

A: Parent material elasticity (such as the distinct spring-back coefficients of 6061-T6 aluminum versus ductile iron) dictates the required radial interference fit. Aluminum has higher elastic recovery and lower stiffness compared to cast iron, requiring precise sleeve wall tuning to prevent permanent bore enlargement or cracking while ensuring a gas-tight seal.

Q: Can these plugs be removed and re-installed after servicing?

A: No. Expansion plugs rely on permanent plastic deformation of the sleeve against the bore wall. Once installed, they must be drilled out and replaced with a new plug if the internal channel requires servicing.

Q: Do you provide free samples for engineering evaluation?

A: Yes, standard sample kits are available for qualified engineering and procurement teams conducting prototype testing and burst-pressure validation.



modular-1
Request a Quote

To receive a formal quotation, technical data sheets, or sample evaluation sets, please provide the following project details:
Part Number or Dimensions (Bore diameter & length)
Parent Material (Aluminum, Steel, Cast Iron)
Maximum Working Pressure & Fluid Type
Estimated Annual Volume / Blanket Order Schedule
Contact our engineering sales team directly at [Your Email/Contact Form Link] for immediate technical assistance.
